Groovy DSL Builders #1: The Concept

The builder pattern is used to create complex objects with constituent parts that must be created in the same order or using a specific algorithm. An external class controls the construction algorithm. — The Gang of Four

Groovy is a language where domain-specific languages (DSL) are the first class citizens. There is a whole page in the documentation dedicated to writing DSL:

Builder pattern has its special place among the other DSL approaches because of an ability to delegate closures to different objects which allows creating compact and easily readable code-as-data. Here is the example of one of the built-in builder JsonBuilder from the official documentation above:

StringWriter writer = new StringWriter()
StreamingJsonBuilder builder = new StreamingJsonBuilder(writer)
builder.records {
car {
name 'HSV Maloo'
make 'Holden'
year 2006
country 'Australia'
record {
type 'speed'
description 'production pickup truck with speed of 271kph'
String json = JsonOutput.prettyPrint(writer.toString())

There are many other builders present directly it the Groovy codebase which could be used as inspiration:

In this series, we are not going to use any of these as they are providing poor developer experience. I would like you to show how to step-by-step implement your own builder which will benefit from excellent IDE support as well as Groovy’s static compilation.

As an example, I’ve chosen to create DSL for diagrams which help to create simple UML diagram online and which data model is relatively simple. Diagram’s Diagram

If we want to describe the Order’s example with plain old Groovy features we can just use language features such as map constructor:

Diagram diagram =  new Diagram()diagram.notes.add(new Note(
text: 'You can stick notes on diagrams too!',
color: 'skyblue'
Type customer = new Type(name: 'Customer')
Type order = new Type(name: 'Order')
Type lineItem = new Type(name: 'LineItem')
Type deliveryMethod = new Type(name: 'DeliveryMethod')
Type product = new Type(name: 'Product')
Type category = new Type(name: 'Category')
Type nationalDeliveryMethod = new Type(name: 'National')
Type internationalDeliveryMethod = new Type(name: 'International')
diagram.relationships.add(new Relationship(
source: customer,
sourceCardinality: '1',
destinationTitle: 'orders',
destination: order,
destinationCardinality: '0..*',
type: RelationshipType.AGGREGATION
diagram.relationships.add(new Relationship(
source: order,
sourceCardinality: '*',
destination: lineItem,
destinationCardinality: '*',
type: RelationshipType.COMPOSITION
diagram.relationships.add(new Relationship(
source: order,
destination: deliveryMethod,
destinationCardinality: '1'
diagram.relationships.add(new Relationship(
source: order,
sourceCardinality: '*',
destination: product,
destinationCardinality: '*'
diagram.relationships.add(new Relationship(
source: category,
destination: product,
bidirectional: true
diagram.relationships.add(new Relationship(
source: nationalDeliveryMethod,
destination: deliveryMethod,
type: RelationshipType.INHERITANCE
diagram.relationships.add(new Relationship(
source: internationalDeliveryMethod,
destination: deliveryMethod,
type: RelationshipType.INHERITANCE

You can see that it takes many lines of code to write just a very simple diagram. In particular, we need to take care of creating new objects and adding them into particular collections.

Diagram class and its companion in this example are a just plain old Groovy object which uses toString method to build the diagram:

class Diagram {

Collection<Note> notes = new LinkedHashSet<>()
Collection<Type> types = new LinkedHashSet<>()
Collection<Relationship> relationships = new LinkedHashSet<>()

String toString() {
assert types

StringWriter stringWriter = new StringWriter()
PrintWriter printWriter = new PrintWriter(stringWriter)

for (Note note in notes) {

Collection<Type> orphanTypes = new LinkedHashSet<>(types)

for (Relationship relationship in relationships) {


for (Type type in orphanTypes) {

return stringWriter.toString()


The produced YUML format is on the other hand very compact:

[note: You can stick notes on diagrams too!{bg:skyblue}]
[Customer]<>1-orders 0..*>[Order]

This will result in a very familiar graph to any YUML user:

Order’s Diagram

The code is available on GitHub under 01-simple tag:

git clone
cd yuml-dsl-builder
git checkout 01-simple

In the next post in this series The Essence: The closures’ basics we will simplify the code using Closures.
